Sunway N Type TOPcon Bifacial 108 Cells 425W-440W Solar module

Category Full Black Solar Panel

Cell(mm)	N Type TOPcon 182*91
Weight(kg)	25.8kg
30mmCable Cross Section Size (mm²)	4
4Cable Cross Section Length (mm)	300
Junction Box	IP68

widely used of the most popular and mature type of modules for solar system
High power output and highest conversion efficiency of 22.30%
Anti-reflective and anti-soiling surface reduces power loss from dirt and dust
Outstanding performance in low-light irradiance environments
Excellent mechanical load resistance: Certified to withstand high wind loads (2400Pa) and Snow loads (5400Pa）
Positive power tolerance: 0~+5W

Electrical Parameters
Module	SW425N-108 ~SW440N-108
Encapsulation	Glass/Eva/Cell/Eva/Glass
Maximum Power Pmax(W)	425	430	435	440
Maximum Power Voltage (Vmp/V)	31.70	31.88	32.06	35.55
Maximum Power Current (Imp/A)	13.41	13.49	13.57	13.65
Open Circuit Voltage(Voc/V)	38.30	38.49	38.68	42.88
Short Circuit Current (Isc/A)	14.15	14.23	14.31	14.39
Module Efficiency (%)	21.80	22.00	22.30	22.50
Power Tolerance (W)	0~+5W
Temperature Coefficient of Isc (αIsc)	+0.046%/ C
Temperature Coefficient of Voc (βVoc)	-0.25%/C
Temperature Coefficient of Pmax(γPmp)	-0.30%/ C
STC	Irradiance 1000W/m, Cell Temperature 25 ℃, Air Mass 1.5
